Radius Gages

Radius gages, which are also often called fillet gages, are special tools utilized for measuring any given component’s radius. The measurement requires a source of light placed behind the actual part being measured. The leaf is placed against the edge to be checked, with a light gap between the curves indicating a mismatch which needs corrections. These tools are used to find out the radii of any concave and convex surfaces. Their leaves come ranged in accordance with their sizes and high exactness is guaranteed.

Such instruments are utilized by professionals of many trades, including high-precision machinists, clock makers, turners, and many others. We have them in a variety of different shapes and sizes, covering all possible requirements. Thanks to high-quality rust-resistant material constructions, typically stainless steel, these tools can be utilized for decades on end. Whether you are a handyman who needs to measure the radii of a window frame or a mechanic having to assess piston ring gaps and bearing clearances, our radius gages will help you do the job with maximum accuracy.
